#21 Displaying The Optimized Images

In this article we will see how to create the ui for displaying the original and optimized images from the previous article. One of the more interesting parts is seeing how to read the sizes of the files located on the server and to organize the results using linq for efficient display on the screen.

Parts

Code behind

  • WebUi
    • Pages
      • Optimizing-Images.cshtml.cs

To display our images so that we can visual compare the original with the optimized versions we will start by adding the code that we need to our code behind (a). To make things easier for this example I have included three different classes in this one file which normally I would not suggest doing.

Optimizing-Images.cshtml.cs

using System.Collections.Generic;
using System.IO;
using System.Linq;
using Microsoft.AspNetCore.Hosting;
using Microsoft.AspNetCore.Mvc.RazorPages;

namespace WebUi.Pages {
    public class OptimizingImagesModel : PageModel
    {
        private readonly IHostingEnvironment _env;

        public OptimizingImagesModel(IHostingEnvironment env)
        {
            _env = env;
            Images = new List<ImageCollection>();
        }

        public List<ImageCollection> Images { get; }

        public void OnGet()
        {
            var originals = Directory
                .EnumerateFiles($"{_env.WebRootPath}/images/optimizing-images/originals/")
                .Select(x => new FileInfo(x))
                .ToArray();

            var optimized = Directory
                .EnumerateFiles($"{_env.WebRootPath}/images/optimizing-images/")
                .Select(x => new FileInfo(x))
                .AsQueryable();

            foreach (var info in originals)
            {
                var images = new ImageCollection(info);
                var infoNameWithoutExtension = Path.GetFileNameWithoutExtension(info.Name);
                var filteredOptimized = optimized
                    .Where(x => Path.GetFileNameWithoutExtension(x.Name) == infoNameWithoutExtension);
                images.AddRange(filteredOptimized);
                Images.Add(images);
            }
        }
    }

    public class ImageCollection
    {
        private readonly Image _original;

        public ImageCollection(FileInfo info)
        {
            _original = new Image(info, true);

            Images = new List<Image>{ _original };
            Type = info.Extension.Replace(".", "").ToUpper();
        }

        public List<Image> Images { get; }
        public string Type { get; }

        public void AddRange(IQueryable<FileInfo> images)
        {
            Images.AddRange(images.Select(x => new Image(x, false, _original.Length)));
        }
    }

    public class Image
    {
        public Image(FileInfo file, bool isOriginal, long originalLength = 1)
        {
            var extension = file.Extension;

            Length = file.Length;
            NameWithExtension = file.Name;

            NameWithoutExtension = NameWithExtension.Replace(extension, "");
            ReductionPercentage = isOriginal
                ? string.Empty
                : (1 - Length / (float)originalLength).ToString("P");
            Size = $"{Length / 1000f}kb";

            if (isOriginal)
            {
                Label = "Original";
                Src = $"/images/optimizing-images/originals/{NameWithExtension}";
            }
            else
            {
                switch (extension)
                {
                    case ".jpeg":
                        Label = "MozJPEG";
                        break;
                    case ".png":
                        Label = "OptiPNG";
                        break;
                    case ".webp":
                        Label = "WebP";
                        break;
                    default:
                        Label = extension;
                        break;
                }
                Src = $"/images/optimizing-images/{NameWithExtension}";
            }
        }

        public string Label { get; }
        public long Length { get; }
        public string NameWithExtension { get; }
        public string NameWithoutExtension { get; }
        public string ReductionPercentage { get; }
        public string Size { get; }
        public string Src { get; }
    }
}
(a) The code behind for our page as well as two separate helper classes.

Displaying the results

  • WebUi
    • Pages
      • Optimizing-Images.cshtml

With our model created it takes just a few lines of code to be able to see the results of our image optimization along side of the original images (b).

Optimizing-Images.cshtml

@page
@model WebUi.Pages.OptimizingImagesModel

@{
    ViewData["Title"] = "Optimizing Images";
}

<div style="font-size: 32px;">
    @foreach (var imagesCollection in Model.Images)
    {
        <h2>@imagesCollection.Type</h2>
        <div style="display: flex;">
            @foreach (var image in imagesCollection.Images)
            {
                <div>
                    <label>@image.Label @image.ReductionPercentage (@image.Size)</label>
                    <img src="@image.Src">
                </div>
            }
        </div>
    }
</div>
(b) The razor code that we need to be able to see the optimized images along side of the originals.
